HS24G3311 is a combination of a wireless transceiver that works in 2.4GHz universal ISM band and a Flash MCU named HS16F3311. The RF part of the chip consists of  receiver, transmitter, frequency synthesizer, GFSK modem and other functional modules. Built-in CRC, retransmission mechanisms and supporting BLE greatly simplify system design and optimize performance.

The MCU part of it integrates touch module to develop touch applications. The application circuit of the chip is simple, requiring very few components to transmit or receive signal well.

¡ôInternal 2K*16-bit ROM

¡ôInternal 128K*8-bit SRAM

¡ôInternal 128K*8-bitEEPROM

¡ô3 channels of timer: 1*8bit£¬1*12bit£¬1*16bit

¡ô 3 channels of 12-bit PWM with dead-time, 3 channels of 8-bit PWM

¡ô 5-channel touch module

¡ôfrequency range 2402-2480MHZ£¬providing 80 channels

 ¡ô maximum air data rate£º1Mbps

¡ômaximum output power 6dBm£¬sensitivity -96dBm £¨62.5kbps£©

¡ô supporting 2M high-speed IIC communications

¡ôfrequency hopping supported

¡ôtransmitting current 26mA£¨5dbm£©

 ¡ôreceiving current 15mA

¡ôcurrent in sleep mode less than 5uA£¨3.3V£©

¡ôOperating voltage: 2.4V~3.7V

¡ôOperating temperature-20¡æ ~ + 85¡æ

¡ôthe communication distance in open area 100 meters at transmission power 7dBm/62.5 Kbps

¡ô supporting BLE

¡ô package SOP16
